General Information
- Model: FB40/FB45?FB50
- Lifting capacity: 4,000kg-5,000kg
- Maximum lifting height: 6,000mm
The Trust Horse NL Series 4.0–Mini 5.0 ton Lithium Battery Forklift combines a compact design with impressive load capacity, making it an ideal solution for medium- to heavy-duty material handling applications.
Powered by advanced lithium battery technology, the NL Series offers fast charging, quiet operation, zero emissions, and maintenance-free performance. Compared with conventional diesel forklifts, it significantly reduces noise, vibration, and operating costs while maintaining powerful lifting performance, excellent stability, and reliable operation under demanding working conditions.
Designed for productivity and sustainability, the NL Series 4.0–Mini 5.0 ton is well suited for warehouses, logistics centers, manufacturing plants, building material industries, and other industrial environments requiring efficient heavy-load handling.
Main Specification
|
Model |
FB40 |
FB45 |
FB50 |
|
|
Rated Load Capacity |
Q(kg) |
4000 |
4500 |
5000 |
|
Load Centre |
c(mm) |
500 |
500 |
500 |
|
Length to Face of Fork (Without Fork) |
l2(mm) |
3215 |
3215 |
3215 |
|
Overall Width |
b1(mm) |
1485 |
1485 |
1485 |
|
Overhead Guard Height |
h5(mm) |
2260 |
2260 |
2260 |
|
Turning Radius (Outside) |
Wa(mm) |
2880 |
2880 |
2880 |
|
Travel Speed (Full Load / No Load) |
km/h |
14/15 |
14/15 |
14/15 |
|
Max.Gradeability (Full Load) |
% |
15 |
15 |
15 |
|
Wheelbase |
y(mm) |
2000 |
200 |
-1600 |
|
Total Weight |
kg |
6305 |
6505 |
6805 |
|
Battery |
V/Ah |
76.8V/450AH |
76.8V/450AH |
76.8V/450AH |
