General Information
- Model: FB30/FB35
- Lifting capacity: 3,000kg-3,500kg
- Maximum lifting height: 6,000mm
The Trust Horse V Series Lithium Battery Forklift represents the next generation of electric material handling equipment, featuring a completely redesigned platform that delivers outstanding performance, durability, and operator comfort.
Powered by advanced lithium battery technology, intelligent electronic control systems, and high-efficiency full AC motors, the V Series provides powerful acceleration, smooth handling, and exceptional energy efficiency. The combination of innovative engineering and rugged construction makes it an ideal replacement for traditional internal combustion forklifts.
With extended operating hours, fast charging capability, zero emissions, low maintenance requirements, and reduced operating costs, the Trust Horse V Series is designed to meet the demands of modern warehouses, logistics centers, manufacturing plants, and distribution facilities. It offers businesses a reliable, productive, and environmentally friendly material handling solution for the future.
Main Specification
|
Model |
FB30 |
FB35 |
|
|
Rated Load Capacity |
Q(kg) |
3000 |
3500 |
|
Load Cener |
c(mm) |
500 |
500 |
|
Wheelbase |
y(mm) |
1750 |
1750 |
|
Total Weight |
kg |
4430/4455 |
4900/4925 |
|
Overhead Guard Height |
h6(mm) |
2265 |
2265 |
|
Length to Face of Fork (Without Fork) |
l2(mm) |
2580 |
2580 |
|
Overall Width |
b1(mm) |
1225 |
1225 |
|
Turning Radius (Outside) |
Wa(mm) |
2330 |
2330 |
|
Travel Speed (Full Load) |
km/h |
14/18 |
14/17 |
|
Travel Speed (No Load) |
km/h |
15/19 |
15/18 |
|
Max.Gradeability (Full Load) |
% |
15/19 |
15/19 |
|
Max.Gradeability (No Load) |
% |
15/20 |
15/20 |
|
Battery |
V/Ah |
76.8V/280Ah 76.8V/304Ah |
76.8V/280Ah 76.8V/304Ah |
