General Information
- Model: FBRS16NH-AC/FBRS18NH-AC/FBRS20NH-AC
- Lifting capacity: 1,600/1,800kg/2,000kg
- Maximum lifting height: 6,000mm
The Trust Horse Reach Truck is engineered as a dedicated warehouse solution for efficient pallet handling, high-level storage, and modern intralogistics operations.
Featuring advanced ergonomic design, high-performance systems, and modern control technology, the Reach Truck delivers excellent maneuverability, precise lifting, and stable operation. It helps businesses maximize storage capacity, improve material handling productivity, and enhance overall warehouse efficiency.
Designed for a wide range of warehouse and intralogistics applications, the Trust Horse Reach Truck is an ideal solution for distribution centers, logistics warehouses, high-density storage facilities, and high-level racking systems, especially where efficient operation in narrow aisles is essential.
Main Specification
|
Model |
FBRS16NH-AC |
FBRS18NH-AC |
FBRS20NH-AC |
|
|
Rated Load Capacity |
Q (kg) |
1600 |
1800 |
2000 |
|
Load Centre |
C (mm) |
600 |
600 |
600 |
|
Overall Length (Without Fork) |
L1 (mm) |
1926 |
2026 |
2026 |
|
Overall Width |
B1 (mm) |
1270 |
1270 |
1270 |
|
Height to Safeguard |
H5 (mm) |
2195 |
2195 |
2195 |
|
Min. Turning Radius |
Wa (mm) |
1750 |
1850 |
1850 |
|
Wheelbase |
Y (mm) |
1500 |
1600 |
1600 |
|
Travel Speed (Full Load) |
km/h |
9 |
9 |
9 |
|
Travel Speed (No Load) |
km/h |
9.5 |
9.5 |
9.5 |
|
Max.Gradeability (Full Load) |
% |
10 |
10 |
10 |
|
Total Weight (Include Battery Box) |
kg |
4115 |
4150 |
4185 |
|
Battery |
V/Ah |
48/560 |
48/700 |
48/700 |
