General Information
- Model: FB30
- Lifting capacity: 3,000kg
- Maximum lifting height: 6,000mm
Featuring advanced lithium battery technology, the VE Series delivers fast charging, quiet operation, zero emissions, and low maintenance requirements, providing an efficient and cost-effective solution without compromising performance or reliability.
Designed for warehouses, logistics centers, distribution facilities, manufacturing plants, and businesses seeking an economical electric forklift, the Trust Horse VE Series offers the perfect balance of productivity, efficiency, and value.
Main Specification
|
Model |
FB30 |
|
|
Rated Load Capacity |
Q(kg) |
3000 |
|
Load Centre |
c(mm) |
500 |
|
Wheelbase |
y(mm) |
1750 |
|
Total Weight |
kg |
4140 |
|
Overhead Guard Height |
h6(mm) |
2250 |
|
Length to Face of Fork (Without Fork) |
l2(mm) |
2580 |
|
Overall Width |
b1(mm) |
1180 |
|
Turning Radius (Outside) |
Wa(mm) |
2270 |
|
Travel Speed (Full Load) |
km/h |
11 |
|
Travel Speed (No Load) |
km/h |
12 |
|
Max.Gradeability (Full Load) |
% |
12 |
|
Max.Gradeability (No Load) |
% |
15 |
|
Battery |
V/Ah |
80V/135Ah |
